DJI RS 4 (ประกันศูนย์)

• Accessory Port
  Ronin Series Accessories (RSA)/NATO Ports
  1/4″-20 Mounting Hole
  ‌Cold Shoe
  Video Transmission Port (USB-C)
  RSS Camera Control Port (USB-C)
  Focus Motor Port (USB-C)

• Battery
  Model: BHX711-3000-7.2‌‌V
  Type: LiPo 2S
  Capacity: 3000 mAh
  Energy: 21 Wh
  Max Runtime: 12 hours (Measured with the gimbal balanced in a level and stationary state. ‌When the gimbal is in motion, the operating time will be reduced.)
  Charging Time: Approx. 2.5 hours (Measured with a charger supporting 18W fast charging. It is recommended to use chargers supporting PD protocol.)
  Suggested Charging Temperature: 5° to 40° C (41° to 104° F)

• Connections
  Bluetooth 5.1
  Charging Port (USB-C)

• Ronin App Requirements
  iOS 11.0 or above
  Android 8.0 or above

• Languages Supported by the Touchscreen
  English, Simplified Chinese, Traditional Chinese, German, French, Korean, Japanese, Spanish, Portuguese (Brazil), Russian, Thai

Working Performance

• Tested Payload
  3 kg (6.6 lbs)

• Maximum Controlled Rotation Speed
  Pan: 360°/s
  Tilt: 360°/s
  Roll: 360°/s

• Mechanical Range
  Pan Axis: 360° continuous rotation
  Roll Axis: -95° to +240°
  Tilt Axis: -112° to +214°

Mechanical & Electrical Properties

• Operating Frequency
  2.400-2.4835 GHz

• Bluetooth Transmitter Power
  < 8 dBm

• Operating Temperature
  -20° to 45° C (-4° to 113° F)

• Weight
  ‌Gimbal: Approx. 1066 g (2.35 lbs)
  Grip: Approx. 203 g (0.45 lbs)
  ‌Extended Grip/Tripod (Plastic): Approx. 183 g (0.4 lbs)
  Upper and Lower Quick-Release Plates: Approx. 98 g (0.22 lbs)

• Dimensions
  ‌Folded: 245×255×75 mm (L×W×H, excluding camera, grip, and the Extended Grip/Tripod)
  Unfolded: 370×191×189 mm (L×W×H, height includes grip and excludes the Extended Grip/Tripod)

DJI Ronin Image Transmitter

• Connections
  Power/Communication Port (USB-C)
  HDMI Port (Mini HDMI)
  RSS Camera Control Port (USB-C)

• Expansion Port
  Cold Shoe

• Operating Frequency
  2.400-2.4835 GHz
  5.725-5.850 GHz

• Weight
  126 g (0.27 lbs)

• Dimensions
  82×63×24 mm (L×W×H)

• Transmitter Power (EIRP)
  ‌2.400-2.4835 GHz:
  < 25 dBm (FCC)
  < 20 dBm (CE/SRRC/MIC)

  5.725-5.850 GHz:
  < 25 dBm (FCC/SRRC)
  < 14 dBm (CE)

• Battery
  Capacity: 2970 mAh
  Compatible Charger: 5 V/2 A
  Charging Time: Approx. 2.5 hours
  Operating Time: Approx. 3.5 hours

• Transmission Range
  200 m (SRRC/FCC)
  100 m (CE)

  ^{‌Measured in an unobstructed environment free of interference.}

• Latency
  60 ms

• Operating Current/Voltage
  900 mA/3.7 V

• Operating Temperature
  0° to 45° C (32° to 113° F)
